6. Exploring Advanced Features#

This notebook is target at advanced users that want, among other things, access MOA objects directly using the Python API from capymoa.

  • Examples on how to use any MOA Classifier or Regressor from capymoa

  • An example of how preprocessing (from MOA) can be used.

  • Comparing a SKLearn model against a MOA model

  • A variation of Tutorial 5: Creating a new classifier in CapyMOA which uses MOA learners, thus accessing MOA (Java) objects directly

  • How to log experiments using TensorBoard alongside the PyTorch API. This extends Tutorial 3: Using Pytorch with CapyMOA

  • Creating a synthetic stream with concept drifts using the MOA CLI directly


More information about CapyMOA can be found in https://www.capymoa.org

last update on 03/05/2024

1. Using any MOA learner#

  • CapyMOA gives you access to any MOA classifier or regressor

  • For some of the MOA learners there are corresponding Python objects (such as the HoeffdingTree or Adaptive Random Forest Classifier). However, MOA has over a hundred learners, and more are added constantly.

  • To allow advanced users to access any MOA learner from CapyMOA, we included the MOAClassifier and MOARegressor generic wrappers.

[1]:
from capymoa.evaluation import prequential_evaluation
from capymoa.base import MOAClassifier
from capymoa.datasets import RBFm_100k
# This is an import from MOA
from moa.classifiers.trees import HoeffdingAdaptiveTree

rbf_100k = RBFm_100k()

# Creates a wrapper around the HoeffdingAdaptiveTree, which then can be used as any other capymoa classifier
HAT = MOAClassifier(schema=rbf_100k.get_schema(), moa_learner=HoeffdingAdaptiveTree)

results_HAT = prequential_evaluation(stream=rbf_100k, learner=HAT, window_size=4500, max_instances=50000)

print(f"Cumulative accuracy = {results_HAT['cumulative'].accuracy()}, wall-clock time: {results_HAT['wallclock']}")
display(results_HAT['windowed'].metrics_per_window())
Downloading RBFm_100k.arff
100% [..........................................................................] 9037474 / 9037474Cumulative accuracy = 59.57599999999999, wall-clock time: 1.4610631465911865
classified instances classifications correct (percent) Kappa Statistic (percent) Kappa Temporal Statistic (percent) Kappa M Statistic (percent) F1 Score (percent) F1 Score for class 0 (percent) F1 Score for class 1 (percent) F1 Score for class 2 (percent) F1 Score for class 3 (percent) ... Precision for class 1 (percent) Precision for class 2 (percent) Precision for class 3 (percent) Precision for class 4 (percent) Recall (percent) Recall for class 0 (percent) Recall for class 1 (percent) Recall for class 2 (percent) Recall for class 3 (percent) Recall for class 4 (percent)
0 4500.0 50.000000 33.449507 34.858135 27.768860 45.089567 53.487412 33.012821 62.374245 13.945578 ... 39.845261 67.685590 29.496403 47.644540 43.338015 57.142857 28.180575 57.835821 9.131403 64.399421
1 9000.0 49.466667 32.401117 35.287422 28.332808 41.328952 56.127745 25.129983 61.844725 2.307692 ... 34.855769 68.228404 6.185567 45.596376 41.013784 59.175084 19.647696 56.553398 1.418440 68.274303
2 13500.0 52.422222 36.245962 38.846044 32.031746 45.928811 59.177456 25.333333 53.851590 18.657938 ... 39.820359 65.017065 31.318681 51.899384 43.756287 66.071429 18.575419 45.958987 13.286713 74.888889
3 18000.0 59.311111 46.626403 47.309353 41.632133 57.974404 59.917012 34.180139 58.620690 64.179104 ... 44.223108 56.342857 75.704225 64.530457 56.441207 62.946818 27.854454 61.090458 55.699482 74.614820
4 22500.0 64.555556 54.112305 54.258675 48.943662 63.436739 67.889126 52.967359 60.546875 63.816475 ... 62.962963 61.917443 57.954545 68.314763 63.573514 70.629991 45.710627 59.235669 70.997680 71.293605
5 27000.0 60.111111 48.455842 48.670289 44.375581 58.755137 68.893204 49.307075 58.830549 55.581395 ... 58.885017 56.536697 54.566210 60.080321 58.558489 73.671096 42.409034 61.318408 56.635071 58.758837
6 31500.0 60.666667 48.797681 49.225473 44.058154 59.622479 69.438669 47.246608 56.351039 61.557478 ... 56.813820 52.928416 66.223404 58.839590 58.587577 70.227082 40.437158 60.246914 57.505774 64.520958
7 36000.0 62.488889 51.365841 51.977240 46.666667 62.079191 67.826087 55.932203 53.044496 67.179487 ... 61.682243 50.727884 67.007673 65.527489 61.832537 68.997473 51.162791 55.582822 67.352185 66.067416
8 40500.0 57.933333 45.320224 45.852403 39.559387 56.433686 65.095729 35.967742 56.277603 61.290323 ... 43.984221 57.106274 59.507830 64.431725 56.395784 75.298126 30.422920 55.472637 63.182898 57.602339
9 45000.0 72.000000 63.510428 63.636364 59.420290 71.308445 71.458075 66.176471 72.941176 69.961977 ... 70.977918 71.480583 75.000000 74.647887 70.422343 74.121680 61.983471 74.462705 65.558195 75.985663
10 49500.0 66.177778 56.005059 55.820029 51.926721 66.012305 62.703583 61.891516 62.087186 70.573871 ... 65.058480 65.096953 71.534653 69.770674 65.432668 63.900415 59.018568 59.343434 69.638554 75.262369
11 50000.0 65.400000 54.995471 54.869565 50.712251 65.018349 61.386139 60.445682 61.479100 68.827930 ... 63.265306 63.479416 70.408163 70.110957 64.466325 62.155388 57.866667 59.600998 67.317073 75.391499

12 rows × 23 columns

1.1 Checking the hyperparameters for the MOA CLI#

  • MOA objects can be parametrized using the MOA CLI (Command Line Interface)

  • Sometimes you may not know the relevent parameters for moa_learner, moa_learner.CLI_help() presents all the hyperparameters available for the moa_learner object.

[2]:
from moa.classifiers.meta import AdaptiveRandomForest

arf = MOAClassifier(schema=rbf_100k.get_schema(), moa_learner=AdaptiveRandomForest)

print(arf.CLI_help())
-l treeLearner (default: ARFHoeffdingTree -e 2000000 -g 50 -c 0.01)
Random Forest Tree.
-s ensembleSize (default: 100)
The number of trees.
-o mFeaturesMode (default: Percentage (M * (m / 100)))
Defines how m, defined by mFeaturesPerTreeSize, is interpreted. M represents the total number of features.
-m mFeaturesPerTreeSize (default: 60)
Number of features allowed considered for each split. Negative values corresponds to M - m
-a lambda (default: 6.0)
The lambda parameter for bagging.
-j numberOfJobs (default: 1)
Total number of concurrent jobs used for processing (-1 = as much as possible, 0 = do not use multithreading)
-x driftDetectionMethod (default: ADWINChangeDetector -a 1.0E-3)
Change detector for drifts and its parameters
-p warningDetectionMethod (default: ADWINChangeDetector -a 1.0E-2)
Change detector for warnings (start training bkg learner)
-w disableWeightedVote
Should use weighted voting?
-u disableDriftDetection
Should use drift detection? If disabled then bkg learner is also disabled
-q disableBackgroundLearner
Should use bkg learner? If disabled then reset tree immediately.

2. Using preprocessing from MOA (filters)#

We are working on a more user friendly API for preprocessing, this example just show how one can do that using MOA filters from here

  • Here we use NormalisationFilter filter from MOA to normalize instances in an online fashion.

  • MOA filters syntax wraps the whole stream, so we are always composing commands like `Filter(Stream,

  • We obtain the MOA CLI from the rbf_100k stream, since it can be mapped to a MOA stream, it is possible to obtain that. Comment out the print statements if you would like to inspect the actual creation strings (perhaps to copy and paste that into MOA?)

[3]:
from capymoa.stream import Stream
from capymoa.classifier import OnlineBagging
from capymoa.evaluation import prequential_evaluation
from moa.streams.filters import StandardisationFilter, NormalisationFilter
from moa.streams import FilteredStream

rbf_100k = RBFm_100k()

# print(f'MOA creation string for data: {rbf_100k.moa_stream.getCLICreationString(rbf_100k.moa_stream.__class__)}')

# Create a FilterStream and use the NormalisationFilter
rbf_stream_normalised = Stream(CLI=f"-s ({rbf_100k.moa_stream.getCLICreationString(rbf_100k.moa_stream.__class__)}) \
-f NormalisationFilter ", moa_stream=FilteredStream())

# print(f'MOA creation string for filtered version: {rbf_stream_normalised.moa_stream.getCLICreationString(rbf_stream_normalised.moa_stream.__class__)}')

ob_learner_norm = OnlineBagging(schema=rbf_stream_normalised.get_schema(), ensemble_size=5)
ob_learner = OnlineBagging(schema=rbf_100k.get_schema(), ensemble_size=5)

ob_results_norm = prequential_evaluation(stream=rbf_stream_normalised, learner=ob_learner_norm)
ob_results = prequential_evaluation(stream=rbf_100k, learner=ob_learner)


print(f"Accuracy with online normalization: {ob_results_norm['cumulative'].accuracy()}")
print(f"Accuracy without normalization: {ob_results['cumulative'].accuracy()}")
Accuracy with online normalization: 61.815
Accuracy without normalization: 60.357000000000006

3. Comparing a MOA and SKLearn models#

  • This simple example shows how it is simple to compare a MOA and a SKLearn regressors.

  • For the sake of this example, we are using the wrappers

  • SKClassifier (and SKRegressor) are parametrized directly as part of the object initialization

  • MOAClassifier (and MOARegressor) are parametrized through a CLI (a separate parameter)

[4]:
from capymoa.base import SKClassifier, MOAClassifier
from capymoa.datasets import CovtypeTiny
from capymoa.evaluation import prequential_evaluation_multiple_learners
from capymoa.evaluation.visualization import plot_windowed_results

from sklearn.linear_model import SGDClassifier
from moa.classifiers.trees import HoeffdingTree

covt_tiny = CovtypeTiny()

sk_sgd = SKClassifier(schema=covt_tiny.schema, sklearner=SGDClassifier(loss='log_loss', penalty='l1', alpha=0.001))
moa_ht = MOAClassifier(schema=covt_tiny.schema, moa_learner=HoeffdingTree, CLI="-g 50")

results = prequential_evaluation_multiple_learners(stream=covt_tiny, learners={'sk_sgd':sk_sgd, 'moa_ht':moa_ht}, window_size=100)
plot_windowed_results(results['sk_sgd'], results['moa_ht'], ylabel="accuracy")
Downloading covtype_n1000.arff
100% [..............................................................................] 21381 / 21381
../_images/notebooks_06_advanced_API_8_1.png

4. Creating Python learners with MOA Objects#

  • This example follow the example from 06_new_learner which shows how to create a custom online bagging implementation.

  • Here we also create an online bagging implementation, but the base_learner is a MOA class

[5]:
from capymoa.base import Classifier, MOAClassifier
from moa.classifiers.trees import HoeffdingTree
from collections import Counter
import numpy as np
import random
import math

def poisson(lambd, random_generator):
    if lambd < 100.0:
        product = 1.0
        _sum = 1.0
        threshold = random_generator.random() * math.exp(lambd)
        i = 1
        max_val = max(100, 10 * math.ceil(lambd))
        while i < max_val and _sum <= threshold:
            product *= (lambd / i)
            _sum += product
            i += 1
        return i - 1
    x = lambd + math.sqrt(lambd) * random_generator.gauss(0, 1)
    if x < 0.0:
        return 0
    return int(math.floor(x))

class CustomOnlineBagging(Classifier):
    def __init__(self, schema=None, random_seed=1, ensemble_size=5, moa_base_learner_class=None, CLI_base_learner=None):
        super().__init__(schema=schema, random_seed=random_seed)

        self.random_generator = random.Random()
        self.CLI_base_learner = CLI_base_learner

        self.ensemble_size = ensemble_size
        self.moa_base_learner_class = moa_base_learner_class

        # Default base learner if None is specified
        if self.moa_base_learner_class is None:
            self.moa_base_learner_class = HoeffdingTree

        self.ensemble = []
        # Create several instances for the base_learners
        for i in range(self.ensemble_size):
            self.ensemble.append(MOAClassifier(schema=self.schema, moa_learner=self.moa_base_learner_class(), CLI=self.CLI_base_learner))

    def __str__(self):
        return 'CustomOnlineBagging'

    def train(self, instance):
        for i in range(self.ensemble_size):
            k = poisson(1.0, self.random_generator)
            for _ in range(k):
                self.ensemble[i].train(instance)

    def predict(self, instance):
        predictions = []
        for i in range(self.ensemble_size):
            predictions.append(self.ensemble[i].predict(instance))
        majority_vote = Counter(predictions)
        prediction = majority_vote.most_common(1)[0][0]
        return prediction

    def predict_proba(self, instance):
        probabilities = []
        for i in range(self.ensemble_size):
            classifier_proba = self.ensemble[i].predict_proba(instance)
            classifier_proba = classifier_proba / np.sum(classifier_proba)
            probabilities.append(classifier_proba)
        avg_proba = np.mean(probabilities, axis=0)
        return avg_proba


4.1 Testing the custom online bagging#

  • We choose to use an HoeffdingAdaptiveTree from MOA as the base learner

  • We also specify the CLI commands to configure the base learner

[6]:
from capymoa.evaluation import prequential_evaluation
from capymoa.stream import stream_from_file
from moa.classifiers.trees import HoeffdingAdaptiveTree

elec_stream = stream_from_file(path_to_csv_or_arff="../data/electricity.csv")

# Creating a learner: using a hoeffding adaptive tree as the base learner with grace period of 50 (-g 50)
NEW_OB = CustomOnlineBagging(schema=elec_stream.get_schema(),
                             ensemble_size=5,
                             moa_base_learner_class=HoeffdingAdaptiveTree,
                             CLI_base_learner="-g 50")

results_NEW_OB = prequential_evaluation(stream=elec_stream, learner=NEW_OB, window_size=4500)

results_NEW_OB['cumulative'].accuracy()
[6]:
82.81912076271186

5. Using TensorBoard with PyTorch in CapyMOA#

  • One can use TensorBoard to visualize logged data in an online fashion

  • We go through all the steps below, including installing TensorBoard

5.1 Install TensorBoard#

Clear any logs from previous runs

rm -rf ./runs
[1]:
!pip install tensorboard
Requirement already satisfied: tensorboard in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (2.16.2)
Requirement already satisfied: absl-py>=0.4 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (2.1.0)
Requirement already satisfied: grpcio>=1.48.2 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (1.62.2)
Requirement already satisfied: markdown>=2.6.8 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (3.6)
Requirement already satisfied: numpy>=1.12.0 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (1.24.1)
Requirement already satisfied: protobuf!=4.24.0,>=3.19.6 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (5.26.1)
Requirement already satisfied: setuptools>=41.0.0 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (68.2.2)
Requirement already satisfied: six>1.9 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (1.16.0)
Requirement already satisfied: tensorboard-data-server<0.8.0,>=0.7.0 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (0.7.2)
Requirement already satisfied: werkzeug>=1.0.1 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from tensorboard) (3.0.2)
Requirement already satisfied: importlib-metadata>=4.4 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from markdown>=2.6.8->tensorboard) (7.1.0)
Requirement already satisfied: MarkupSafe>=2.1.1 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from werkzeug>=1.0.1->tensorboard) (2.1.3)
Requirement already satisfied: zipp>=0.5 in /Users/gomeshe/miniconda3/envs/capymoa/lib/python3.9/site-packages (from importlib-metadata>=4.4->markdown>=2.6.8->tensorboard) (3.18.1)

5.2 PyTorchClassifier#

  • We define PyTorchClassifier and NeuralNetwork classes similarly to those from Tutorial 3: Using Pytorch with CapyMOA

[8]:
from capymoa.base import Classifier
import numpy as np
import torch
from torch import nn

torch.manual_seed(1)
torch.use_deterministic_algorithms(True)

# Get cpu device for training.
device = ("cpu")

# Define model
class NeuralNetwork(nn.Module):
    def __init__(self, input_size=0, number_of_classes=0):
        super().__init__()
        self.flatten = nn.Flatten()
        self.linear_relu_stack = nn.Sequential(
            nn.Linear(input_size, 512),
            nn.ReLU(),
            nn.Linear(512, 512),
            nn.ReLU(),
            nn.Linear(512, number_of_classes)
        )

    def forward(self, x):
        x = self.flatten(x)
        logits = self.linear_relu_stack(x)
        return logits


class PyTorchClassifier(Classifier):
    def __init__(self, schema=None, random_seed=1, nn_model: nn.Module = None, optimizer=None, loss_fn=nn.CrossEntropyLoss(), device=("cpu"), lr=1e-3):
        super().__init__(schema, random_seed)
        self.model = None
        self.optimizer = None
        self.loss_fn = loss_fn
        self.lr = lr
        self.device = device

        torch.manual_seed(random_seed)

        if nn_model is None:
            self.set_model(None)
        else:
            self.model = nn_model.to(device)
        if optimizer is None:
            if self.model is not None:
                self.optimizer = torch.optim.SGD(self.model.parameters(), lr=lr)
        else:
            self.optimizer = optimizer

    def __str__(self):
        return str(self.model)

    def CLI_help(self):
        return str('schema=None, random_seed=1, nn_model: nn.Module = None, optimizer=None, loss_fn=nn.CrossEntropyLoss(), device=("cpu"), lr=1e-3')

    def set_model(self, instance):
        if self.schema is None:
            moa_instance = instance.java_instance.getData()
            self.model = NeuralNetwork(input_size=moa_instance.get_num_attributes(), number_of_classes=moa_instance.get_num_classes()).to(self.device)
        elif instance is not None:
            self.model = NeuralNetwork(input_size=self.schema.get_num_attributes(), number_of_classes=self.schema.get_num_classes()).to(self.device)

    def train(self, instance):
        if self.model is None:
            self.set_model(instance)

        X = torch.tensor(instance.x, dtype=torch.float32)
        y = torch.tensor(instance.y_index, dtype=torch.long)
        # set the device and add a dimension to the tensor
        X, y = torch.unsqueeze(X.to(self.device), 0), torch.unsqueeze(y.to(self.device),0)

        # Compute prediction error
        pred = self.model(X)
        loss = self.loss_fn(pred, y)

        # Backpropagation
        loss.backward()
        self.optimizer.step()
        self.optimizer.zero_grad()

    def predict(self, instance):
        return np.argmax(self.predict_proba(instance))

    def predict_proba(self, instance):
        if self.model is None:
            self.set_model(instance)
        X = torch.unsqueeze(torch.tensor(instance.x, dtype=torch.float32).to(self.device), 0)
        # turn off gradient collection
        with torch.no_grad():
            pred = np.asarray(self.model(X).numpy(), dtype=np.double)
        return pred

5.3 PyTorchClassifier + the test-then-train loop + TensorBoard#

  • Here we use instance loop to log relevant log information to TensorBoard

  • These information can be viewed while the processing is happening using TensorBoard

[9]:
from capymoa.evaluation import ClassificationEvaluator
from capymoa.datasets import RBFm_100k
from torch.utils.tensorboard import SummaryWriter

# Create a SummaryWriter instance.
writer = SummaryWriter()
## Opening a file again to start from the beginning
rbf_stream = RBFm_100k()

# Creating the evaluator
evaluator = ClassificationEvaluator(schema=rbf_stream.get_schema())

# Creating a learner
simple_pyTorch_classifier = PyTorchClassifier(
    schema=rbf_stream.get_schema(),
    nn_model=NeuralNetwork(input_size=rbf_stream.get_schema().get_num_attributes(),
                           number_of_classes=rbf_stream.get_schema().get_num_classes()).to(device)
)

i = 0
while rbf_stream.has_more_instances():
    i += 1
    instance = rbf_stream.next_instance()

    prediction = simple_pyTorch_classifier.predict(instance)
    evaluator.update(instance.y_index, prediction)
    simple_pyTorch_classifier.train(instance)

    if i % 1000 == 0:
        writer.add_scalar("accuracy", evaluator.accuracy(), i)

    if i % 10000 == 0:
        print(f"Processed {i} instances")

writer.add_scalar("accuracy", evaluator.accuracy(), i)
# Call flush() method to make sure that all pending events have been written to disk.
writer.flush()

# If you do not need the summary writer anymore, call close() method.
writer.close()
Processed 10000 instances
Processed 20000 instances
Processed 30000 instances
Processed 40000 instances
Processed 50000 instances
Processed 60000 instances
Processed 70000 instances
Processed 80000 instances
Processed 90000 instances
Processed 100000 instances

5.4 Run TensorBoard#

Now, start TensorBoard, specifying the root log directory you used above. Argument logdir points to directory where TensorBoard will look to find event files that it can display. TensorBoard will recursively walk the directory structure rooted at logdir, looking for .*tfevents.* files.

tensorboard --logdir=runs

Go to the URL it provides

This dashboard shows how the accuracy change with time. You can use it to also track training speed, learning rate, and other scalar values.

6. Creating a synthetic stream with concept drifts from MOA#

  • Demonstrates the flexibility of the API, these level of manipulation of the API is expected from experienced MOA users.

  • To use the API like this the user must be familiar with how concept drifts are simulatd in MOA

EvaluatePrequential -l trees.HoeffdingAdaptiveTree -s (ConceptDriftStream -s generators.AgrawalGenerator -d (generators.AgrawalGenerator -f 2) -p 5000) -e (WindowClassificationPerformanceEvaluator -w 100) -i 10000 -f 100

[10]:
from capymoa.stream import Stream
from capymoa.classifier import OnlineBagging
from capymoa.evaluation import prequential_evaluation
from capymoa.evaluation.visualization import plot_windowed_results
from moa.streams import ConceptDriftStream

# Using the API to generate the data using the ConceptDriftStream and AgrawalGenerator.
# The drift location is based on the number of instances (5000) as well as the drift width (1000, the default value)
stream_sea1drift = Stream(moa_stream=ConceptDriftStream(),
                          CLI="-s generators.SEAGenerator -d (generators.SEAGenerator -f 2) -p 5000 -w 1000")

OB = OnlineBagging(schema=stream_sea1drift.get_schema(), ensemble_size=10)

results_sea1drift_OB = prequential_evaluation(stream=stream_sea1drift, learner=OB, window_size=100, max_instances=10000)

plot_windowed_results(results_sea1drift_OB)
../_images/notebooks_06_advanced_API_22_0.png
[ ]:
